Customer Cases

Hand screw press

This press has the advantage of being multifunctional and easy to use.
The project utilizes vide variety of T-FLEX CAD tools.

System for Electrical Discharge Machining of cells in aircraft engine parts

The model consists of an electrode, an electrode holder and a processed part holder.
Project is made in the T-FLEX CAD 16.

Carbon Vacuum Adsorption Vapour Recovery Unit UUVA-02-D

This model utilizes parametrization abilities of the T-FLEX CAD to full extent.

Twenty-Eight-Foot Wooden Steam Boat of the Russian Imperial Navy with a White System Boiler, Model 1870-1875

The 28-foot wooden steam boat of the Russian Imperial Navy with a White system boiler, model 1870-1875.

Project is made in the T-FLEX CAD 15

Precise Tooth Profile

The author was able to create an accurate tooth profile.

The model is made in T-FLEX CAD 16.

Log Semi-trailer

The model is create in the form of a multilevel assembly, created using the bottom-up method

Wooden Clock

The main purpose of the project was to study the capabilities of T-FLEX CAD 16. The project was done at home in free time from the main work. A free Student Edition was used for modeling.

Refrigeration Evaporator

This device was made to replace a failed device at one of the enterprises.

Screw Press for Vegetable Oil Extraction

A screw press for pressing vegetable oil is an import-substituting project. The project is fully developed, contains drawings of parts, assemblies and bill of materials.

Block of Air Coolers

The assembly was modeled using the bottom-up method. In the process of creating the assembly, the parametric capabilities of T-FLEX CAD were actively used.

The assembly of the apparatus consists of more than 60,000 bodies.
